DF40A

(0)No Reviews yet
SKU: WEBDF40A

This is the only engine in the 40 hp class to offer DOHC performance, and also the only engine in its class to incorporate a maintenance-free, oil-bathed timing chain, which provides the outboard with increased durability and maintenance free operation. With larger displacements for increased power and performance, Suzuki's Lean Control System for improved fuel economy and designs that are more compact and lighter in weight than the predecessor, the new DF40A engines also incorporate the Suzuki Troll Mode System. During the 2011 Miami Boat Show, the Boating Writers of America presented Suzuki Marine with the NMMA Innovation Award for the DF40A/DF50A.

Features

  • Multi Point Sequential Electronic Fuel Injection
  • Suzuki Lean burn Control System
  • Suzuki Troll Mode System
  • Direct Ignition
  • Suzuki Easy Start System
  • Over-Rev. Limiter
  • Low Oil Pressure Caution
  • Fully Transistorized Ignition
  • Timing Chain
  • Fresh Water Flushing System
  • Power Trim and Tilt
Specs:   First Edition
Body ColorPearl Nebular Black or Cool White
Recommended Transom Height (inches)L: 20
Starting SystemElectric
Weight LBSL: 229
Engine TypeDOHC 12-Valve
Fuel Delivery SystemMulti Point Sequential Electronic Fuel Injection
No. Of Cylinders3
Piston Displacement inches (cc)57.4 (941)
Bore X Stroke Inches (mm)2.85 x 2.99 (72.5 x 76)
Maximum Output HP40
Operating Range (RPM)5000 - 6000
SteeringRemote (Tiller Kit Optional)
ChokeN/A
Oil Pan Capacity quarts (liter)2.9 (2.7)
Ignition SystemSolid State Direct Ignition
Alternator12V 19A
Trim PositionPower Trim and Tilt
Gear Ratio2.27:1
Standard PropellerOptional See Dealer
Propeller Selection9 - 17

New outboard(s)
New rigging tube and connections
New propeller
Water separator / fuel filter
Engine oil
Miscellaneous rigging supplies
New controls

New harness

New standard gauges

New steering


New upgraded gauges


New battery switch
