DF60AV

(0) No Reviews yet
SKU: WEBDF60AV

The New DF60AV is designed with a "High Energy Rotation" lower unit sporting a 2.42:1 gear ration, which enables this new model to use a bigger 14" propeller - perfect for powering pontoon boats and other large, heavy craft. This mid-range engine is also designed with Lean Burn Fuel Control System, which adjusts the air/fuel mixtrue according to operating conditions. The system significantly improves fuel efficiency across the operating range, from low speeds well up into the cruising range. New DF60AV model is also available with the optional Suzuki Troll Mode System.

Features

  • High Energy Rotation Lower Unit
  • Multi Point Sequential Electronic Fuel Injection
  • Suzuki Lean burn Control System
  • Suzuki Troll Mode System
  • Direct Ignition
  • Suzuki Easy Start System
  • Over-Rev. Limiter
  • Low Oil Pressure Caution
  • Fully Transistorized Ignition
  • Timing Chain
  • Fresh Water Flushing System
  • Power Trim and Tilt
  • Tilt Limit
  • Suzuki Anti-Corrosion System
Body ColorPearl Nebular Black
Recommended Transom Height (inches)L: 20
Starting SystemElectric
Weight LBSL: 253
Engine TypeDOHC 12-Valve
Fuel Delivery SystemMulti Point Sequential Electronic Fuel Injection
No. Of Cylinders3
Piston Displacement inches (cc)57.4 (941)
Bore X Stroke Inches (mm)2.85 x 2.99 (72.5 x 76)
Maximum Output HP60
Operating Range (RPM)5300 - 6300
SteeringRemote (Tiller Kit Optional)
ChokeN/A
Oil Pan Capacity quarts (liter)2.9 (2.7)
Ignition SystemSolid State Direct Ignition
Alternator12V 19A
Trim PositionPower Trim and Tilt
Gear Ratio2.42:1
Standard PropellerOptional See Dealer
Propeller Selection9 - 17

New outboard(s)
New rigging tube and connections
New propeller
Water separator / fuel filter
Engine oil
Miscellaneous rigging supplies
New controls

New harness

New standard gauges

New steering


New upgraded gauges


New battery switch
