| Generator | Type | Revolving field type 2 pole generator |
|---|
| Frequency [Hz] | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Max. AC output [kVA] | 2.2 | 2.7 | 3.2 | 3.7 | 4.6 | 5.5 | 5.5 | 6.6 |
| Cont. AC output [kVA] | 2.0 | 2.5 | 3.0 | 3.5 | 4.2 | 5.0 | 5.0(1.7) | 6.0(2.0) |
| DC output (generator & charger) [V-A] | 12-8.3 | - |
| Voltage [V] | 120, 220, 240, 110 / 220, 120 / 240 | 380 (220) |
| Rated power factor [%] | 100 | 80(100) |
| Phase | Single Phase | 3-phase (single) |
| Excitation system | Self-excitation | Self & separate excitation |
| Engine | Model | L48N5/6-G(E)Y | L70N5/6-G(E)Y | L100N5/6-G(E)Y | L-100N5/6-GEYT |
|---|
| Type | Vertical, 4-cycle, air-cooled diesel engine |
| Displacement [cc] | 219 | 320 | 435 |
| Cont. output [kW/min-1(rpm)] | 2.8/3000 | 3.1/3600 | 4.1/3000 | 4.4/3600 | 5.7/3000 | 6.6/3600 | 5.7/3000 | 6.6/3600 |
| Starting system | Recoil or Recoil / Electric | Electric |
| Combustion system | Direct injection |
| Governor system | All speed by centrifugal weight |
| Fuel oil | Diesel fuel oil |
| Fuel tank capacity [lit.] | 7.2 | 13 |
| Lube oil capacity [lit.] | 0.8 | 1.1 | 1.65 |
| Operation capacity (One tankful)* approx. [hr.] | 7.0 | 6.5 | 9.5 | 8.0 | 7.0 | 6.0 | 5.5 | 4.9 |
| Unit | Noise level at 7m (approx.) [dB (A)] | 79 | 80 | 81 | 82 | 84 | 85 | 84 | 85 |
|---|
| Dimensions L x W x H (Recoil) [mm] | 590 x 416 x 500 | 650 x 496 x 530 | 720 x 480 x 578 | - |
| Dry weight (Recoil) [kg] | 55 | 70 | 95 | - |
| Dimensions L x W x H (Electric) [mm] | 649 x 416 x 500 | 650 x 496 x 530 | 720 x 480 x 578 |
| Dry weight (Electric) [kg] | 64 | 82 | 108 |
